Doepfer A-106-5 12dB SEM Filter

10 600 р. предложить свою цену
Код товара: 43811
Гарантия: 12 месяцев
Статус:

Module A-106-5 is a 12dB multimode filter that is based on the filter circuit of the Oberheim SEM module.

The filter is equipped with a band pass output and a combined low/notch/high pass output. For this output a control knob defines the relation between low and high pass signal. If both signals appear at the same level (i.e. middle position of the Mix knob) one obtains a notch filter. Otherwise the low or high pass signal predominates. The module does not feature self oscillation in contrast to most of the other filters of the A-100 system.

The module generates a distorted audio signal if the level control is set to about 50% (i.e. center position) or more with A-100 standard signals like VCOs.

Power consumption: 30mA at +12V and 20mA at -12V

Depth: 55mm

HP : 8
