Eurorack Module
- CV extension for ES-4, ES-40 or ES-5 module
- 8 CV outputs 3.5 mm mini jack DC coupled
- Output voltages: ± 5.33V hardware calibrated or ± 9.5 V uncalibrated (jumper setting)
- 12 bit D / A conversion
- Power requirement: 41 mA at +12 V, 33 mA at -12 V
- Dimensions (W x D): 4 HP / HP x 49 mm
