Analogue Synthesizer Expander
- Monophonic or 3-voice paraphonic playable
- 3 Discrete VCOs, each with 3 simultaneously switchable waveforms
- Square wave with variable pulse width per VCO
- Switchable hard sync from VCO 2 and 3 to VCO 1
- Noise generator
- Ring modulator
- 4 Selectable VCF types: 24dB ladder lowpass, 24dB ARP lowpass, Juno/Jupiter lowpass with 3 modes (24dB, 12dB, mixed) and 12dB SEM (lowpass and bandpass)
- 4 ADSR envelopes
- 3 Assignable LFOs with 6 waveforms each (triangle, sawtooth, ramp, square, noise and random) with re-trigger function and MIDI clock synchronisation
- VCA with switchable Fuzz stage
- Portamento with linear or exponential characteristic curve
- 8 Preset banks with 99 memory locations each
- 24 Knobs and 18 buttons/switches for direct access to all important parameters
- LC display, encoder and cursor buttons
- Line output: 6.3 mm jack
- Line input: 6.3 mm jack
- MIDI in/out/thru
- Dimensions (W x H x D): 483 x 133 x 205 mm / 19", 3U
- Weight: 4.99 kg
